Metal riser mounted bracket

The design of the metal riser mounted bracket was created to give an alternative to the beam, for the particularly high steps that do not allow a seat height between 40 and 45 cm, in order to optimize costs and facilitate cleaning operations being the step floor free from any structure. Its versatility allows it to be suitable with all OMSI products; its essential and clean line is perfectly matching with any seat

Standard dimensions: depth: 325 mm; width 340 mm; height 280 mm.
(Possibility to change the size as needed.)

Material: hot galvanized FE360 or finished with cataphoresis and painting; extremely strong and anticorrosive.

Installation: directly on the step riser.

Anchoring: seat fixed on the bracket by self-tapping screws; fixation of the complete unit on the step riser in 3 points by means of mechanical anchors, stainless steel nuts and washers.

DIMENSIONS:
